Description
Technical Parameters
| Pressure range | 0~0.6MPa~150MPa | |
| Power supply | 24(12~36V)DC | |
| Singal output | 4-20mA | |
| Pointer accuracy | ±1.6%FS ; ±2.5%FS | |
| Signal accuracy | ±1%FS ; ±1.5%FS | |
| Overload | 150%FS | |
| Dial Filling Material | Silicone oil | |
| Dial Diameter | 100mm | |
| Max Diaphragm Temp. | 125℃ | |
| Length of rod | 33 ; 82mm | |
| Electrical Connection | 5PIN | |
| Process Connection | M20*1.5 ; M18*1.5 | |
Features
1. High cost performance and long service life
2. Easy to install and disassemble
3. Good shock resistance and corrosion resistance
4. Good stability and high reliability
5. With singal output
Application
1. Liquids with high viscosity, easy to crystallize, and easy to solidify
2. Corrosive medium
3. Equipment in the alkali, chemical fiber, dyeing, pharmaceutical, food, and cheese industries
