Description
Technical Parameters
| Measuring range | 1Torr(133Pa) – 10Torr.(1.33kPa) |
| Accuracy | 0.5%F.S;0.25%F.S |
| Power supply | 18~24V DC |
| Output signal | 0~10V DC |
| Measuring medium | Gas |
| Electrical connector | Analog 9PIN |
| Process connection | KF16 |
| Power-on warm-up time | 10min |
Features
• Industry standard connector
• High accuracy: standard ±0.5%FS, ±0.25%FS (optional)
• Precision diaphragm ensures excellent performance
• Wide operating temperature compensation range
• Low circuit noise and fast response
• Not easily affected by changes in environmental conditions
• Excellent overpressure resistance design
Application
1.Plasma etcher
2.Vapor deposition
3.Plasma sterilization
4.Vacuum coating
5.Vacuum distillation
6.Vacuum packaging
7.Vacuum furnace
8.Freeze dryer
