Description
Technical Parameters
| Pressure range | -0.1～0～3MPa | ||
| Overload | 150%FS | ||
| Comprehensive accuracy | 0.1%FS ; 0.25%FS ; 0.5%FS | ||
| Long term stability | ±0.1%FS/year | ||
| Non-linearity | 0.1%FS | ||
| Repeatability | 0.1%FS | ||
| Singal output | 4‐20mA ; 0‐5V ; 0‐10V ; RS485 ; 4‐20mA+hart ; i2c | ||
| Power supply | 24(12~36V)DC | ||
| Storage temperature | ‐20～85℃ | ||
| Operating temperature | ‐20～85℃ (Typical type); ‐20～125℃(Medium to high temperature type) | ||
| Compensation temperature | ‐10～80℃ | ||
| Wetted material | Hastelloy C-276;SS316L;Tantalum | ||
| Housing material | SS304 | ||
| Protection grade | IP65 | ||
| Electrical Connection | M12*1 4-PIN plug-in ; Hirschmann A type ; PG7 gland lead | ||
| Process connection | 1.5 inch tri-clamp ; 2 inch tri-clamp | ||
Features
1. Tri-clamp design，easy installation
2. A variety of industrial standard signal outputs are available
3. Simple appearance design, high cost performance
4.Can be used for medium that are easy to crystallize, precipitate, slurry, etc.
Application
1. Hydraulic, die-casting, constant pressure water supply
2. Light industry, machinery, metallurgy, petrochemical industry
3. Environmental protection, air compressor and other automatic control systems
4. Food, pharmaceutical industry
