Description
Technical Parameters
| Measurement range | 50m H2O |
| Accuracy | 0.1%FS ; 0.25%FS ; 0.5%FS ; 1%FS |
| Long term stability | ±0.2%FS/year |
| Overload | 150%FS |
| Power supply | 12~36V DC |
| Signal output | 4~20mA ; 0-5V ; 0-10V ; RS485 |
| Response Time | ＜3mS |
| Electrical Connection | Gland Lead |
| Storage temperature | -40~85℃ |
| Operating temperature | -20~85℃ |
| Compensation temperature | 0～65℃ |
| Probe material | SS304 |
| Protection grade | IP68 |
Features
1. Chemical industry; reactors, storage tanks
2. Water treatment industry; sedimentation tanks, reservoirs, clear water tanks
4. Food and pharmaceutical industry; raw material tanks, fermentation tanks
5. Urban water supply and drainage; reservoirs, water towers, reservoirs
6. Environmental monitoring; used to monitor the liquid level of industrial wastewater and domestic sewage discharge pools
7. Power industry; boiler drum water level, cooling tower pool level
8. Oil and gas; oil storage tanks, buffer tanks of gathering and transportation pipelines
9. Agriculture and water conservancy; rivers, lakes, reservoirs
Application
1.moist proof, frost proof, seepage prevention
2.Various signal output for industrial standard, flexible calibration
3.High accuracy, good stability
4.High performance pressure-sensitive core with small temperature drift
