Description
Technical Parameters
| Application types | Standard type (diffused silicon) | |
| Dimension | Diameter:Φ19mm (Φ12.6mm ; Φ16mm are optional) | |
| Power supply | I (Current) | V (Voltage) |
| Constant current 1mA | Constant Voltage 5V | |
| Pressure type | G: Gauge pressure | |
| A: Absolute pressure | ||
| Measurement range | -100kPa~0-20kPa~60MPa | |
| Input impedance | 2K～6KΩ | 3K～18KΩ |
| Output impedance | 2K～6KΩ | |
| Zero output | ±2mV | |
| Full scale output | ≤250kPa; 50±5mV | ≤250kPa; 45±5mV |
| ≥500kPa; 60-140mV | ≥500kPa; 50-120mV | |
| Comprehensive accuracy | ±0.1%FS ; ±0.25%FS (Standard) | |
| Operating temperature | -40℃～125℃ | |
| Temperature compensation | ≤35kPa: 0℃～50℃ | |
| Other range: -10℃～70℃ | ||
| Long term stability | ±0.2%/year | |
| Overload | ＜3MPa: 200%FS | |
| ≥3MPa: 150%FS | ||
| Insulation resistance | 100MΩ | |
| Housing / Isolation diaphragm material | SS316L ; Hastelloy C | |
| Natural frequency | ≥10KHZ | |
| Filling liquid | Silicone oil | |
Features
1. Universal size (φ12.6/16/19 optional)
2. Liquid contact material can be selected as needed
3. Gauge pressure/absolute pressure is optional
Application
1. Industrial process control
2. Water supply and drainage system
3. Hydraulic system and switch
4. Liquid level measurement
5. Gas and liquid pressure measurement
