Description
Technical Parameters
| Application types | High stability (monocrystalline silicon) |
| Pressure type | Differential pressure |
| Measurement range | -100kPa~0-10kPa~3MPa |
| Power supply | 5V DC |
| Analog signal | 4-20mA with HART |
| Digital signal | RS485 |
| Input impedance | 5K～7KΩ |
| Output impedance | 5K～7KΩ |
| Comprehensive accuracy | ±0.1%FS ; ±0.25%FS ; ±0.5%FS |
| Operating temperature | -40℃～85℃ |
| Long term stability | ±0.05%/year |
| Insulation resistance | 100MΩ |
| Isolation diaphragm material | SS316L ; Hastelloy C |
| Filling liquid | Silicone oil |
| Natural frequency | ≥10KHZ |
Features
1. High accuracy
2. Good repeatability and stability
3. Calibration and temperature compensation completed
Application
1. Precision control of industrial processes
2. Fluids and switches
3. Liquid level measurement
4. Gas/liquid differential pressure measurement
5. Flow and density measurement
