Description
Technical Parameters
| Temperature measuring element | PT100 ; J ; K ; E (optional) | |
| Measurement range | PT100: -50~600℃ | J、K、E: -200~1300℃ |
| Accruacy | 0.5%FS ; 1%FS | |
| Power supply | 24(12~36)V DC (Amplified signal) ; 10(6~12)V DC (mV Singal) | |
| Signal output | 4-20mA（2-wires） ; 3-wires ; 4-wires | |
| Protection tube material | SS304 ; SS316L ; PTFE | |
| Capillary length | 200 ; 460mm | |
| Length of rod | 152 ; 200 ; 250 ; 300mm | |
| Process connection | 1/2-20UNF ; M14*1.5 | |
Features
1. Multiple industrial standard signal outputs are available
2. Wiring is done by connector or direct lead
3. Zero adjustment and full adjustment functions can be added as required
4. Multiple pressure interfaces are available
Application
1.Chemical fiber drawing equipment
2.Plastic and rubber manufacturing equipment
3.Medicine, food processing, packaging equipment
4. Temperature measurement of other high-temperature fluid equipment
