Description
Technical Parameters
| Pressure range | -0.1～0～25MPa(Diffused silicon type) ; 0～25～150MPa(Strain gauge type) | ||
| Overload | 150%FS | ||
| Comprehensive accuracy | 0.25%FS ; 0.5%FS | ||
| Long term stability | ±0.1%FS/year | ||
| Non-linearity | 0.1%FS | ||
| Repeatability | 0.1%FS | ||
| Singal output | 4‐20mA ; 0‐5V ; 0‐10V ; RS485 | ||
| Power supply | 24(12~36V)DC | ||
| Storage temperature | ‐20～85℃ | ||
| Operating temperature | ‐20～125℃ | ||
| Compensation temperature | ‐10～80℃ | ||
| Wetted material | SS304;SS316L(Customizable) | ||
| Housing material | SS304 | ||
| Protection grade | IP65 | ||
| Electrical Connection | 5-PIN aviation plug-in ; M12*1 4-PIN plug-in ; Hirschmann A type ; PG7 gland lead | ||
| Process connection | G1/4 ; G3/8 ; G1/2 ; 1/2NPT ; 1/4NPT ; M14*1.5 ; M20*1.5, etc. | ||
Features
1. Fluids in medium and high temperature areas
2. Steam pressure measurement and control
Application
1. Hydraulic, die-casting, constant pressure water supply
2. Light industry, machinery, metallurgy, petrochemical industry
3. Environmental protection, air compressor and other automatic control systems
4. Food, pharmaceutical industry
