Description
Technical Parameters
| Product model | CZ-C900 | CZ-C500 | CZ-C150 |
| Measuring parameters | Refractive index (nD), temperature (T), Brix(%) | ||
| Measurement range | nD; 1.33299-1.5177 / Brix; 0.0~90.0 % | nD; 1.33299-1.42009 / Brix; 0.0~50.0% | nD; 1.33299-1.35568 / Brix; 0.0~15.0% |
| Resolution | nD; 0.0005 / Brix; 0.5% / T; 0.1℃ | nD; 0.0001 / Brix; 0.1% / T; 0.1℃ | |
| Accuracy | nD; ±0.0005 / Brix; ±0.5% / T; ±1℃ | nD; ±0.0003 / Brix; ±0.3% / T; ±1℃ | |
| Temperature compensation | 10-60℃ | ||
| Power supply | 12~24V DC | ||
| Signal output | DC 4~20mA or RS485 | ||
| Ambient temperature | 10-60℃ | ||
| Protection grade | IP67 | ||
| Operating pressure | Maximum tolerance 1Mpa | ||
| High & low limit setting | Short circuit reset (4/20mA output) ; Protocol reset (RS485 output) | ||
| Prism material | Artificial sapphire | ||
| Wetted material | Standard; SS316L (optional; 2205; Hastelloy C-276) | ||
| Process medium | Cutting oil; emulsion; sugar content; juice | ||
| Installation type | Tri-clamp (optional; thread, flange) | ||
| Pipeline adapter | Tri-clamp cross pipe fitting ; flange cross pipe fitting ; threaded cross pipe fitting (installation type is Tri-clamp) | ||
| Cleaning accessories | QX-S01、CQX-1A | ||
| Communication Protocol | Standard; modbus (protocol can be customized) | ||
Features
1. All stainless steel design, intrinsically safe and explosion-proof, suitable for various places with explosion-proof requirements
2. Accurate, fast, stable and reliable
3. Uninterrupted real-time concentration measurement output
4. 4-20mA/RS485 dual output
Application
1. Continuous monitoring of soluble solid content (Brix value) in process flows such as evaporation, dissolution, mixing, dilution, and extraction.
2. Real-time detection of concentration of various industrial solutions, such as cutting oil, lubricating oil, cleaning fluid, emulsion, and release agent.
