Description
Technical Parameters
| Application types | High stability (monocrystalline silicon) |
| Pressure type | G: Gauge pressure |
| A: Absolute pressure | |
| Measurement range | -100kPa~0-10kPa~3MPa |
| Power supply | 5V DC ; 9~36V DC ; 12~36V DC |
| Analog signal | 0-5V; 0.5-4.5V; 0-10V; 4-20mA |
| Digital signal | RS485 ; i2C |
| Input impedance | 5K～7KΩ |
| Output impedance | 5K～7KΩ |
| Comprehensive accuracy | ±0.1%FS ; ±0.25%FS |
| Operating temperature | -40℃～85℃ |
| Long term stability | ±0.05%/year |
| Overload | 1600%FS(<2MPa) |
| 800%FS(>2MPa) | |
| Insulation resistance | 100MΩ |
| Isolation diaphragm material | SS316L ; Hastelloy C |
| Filling liquid | Silicone oil |
| Process connection | Thread: M20*1.5 external ; G1/2 external ; 1/2NPT external ; 1/2NPT internal |
Features
1. High accruacy
2. Good repeatability and stability
3. Gauge pressure/absolute pressure are optional
4. Instantaneous pressure resistance can reach 1600%FS
Application
1. Precision control of industrial processes
2. Water supply and drainage systems
3. Hydraulic systems and switches
4. Liquid level measurement
5. Gas and liquid pressure measurement
6. Monitoring systems with large overload pressure requirements
