Description
Technical Parameters
| Application types | High stability (monocrystalline silicon) |
| Pressure type | Differential pressure |
| Measurement range | -100kPa~0-10kPa~3MPa |
| Power supply | 5V DC |
| Signal output | 40-120mA |
| Input impedance | 5K～7KΩ |
| Output impedance | 5K～7KΩ |
| Comprehensive accuracy | ±0.1%FS ; ±0.25%FS ; ±0.5%FS |
| Operating temperature | -40℃～85℃ |
| Long term stability | ±0.05%/year |
| Insulation resistance | 100MΩ |
| Isolation diaphragm material | SS316L ; Hastelloy C |
| Filling liquid | Silicone oil |
| Natural frequency | ≥10KHZ |
Features
1. High accruacy
2. Good repeatability and stability
3. Gauge pressure/absolute pressure are optional
4. Instantaneous pressure resistance can reach 1600%FS
Application
1. Precision control of industrial processes
2. Fluids and switches
3. Liquid level measurement
4. Gas/liquid differential pressure measurement
5. Flow and density measurement
