Description
Technical Parameters
| Measurement range | ‐0.1～0～40MPa |
| Power supply | 24(12～36)V DC |
| Singal output | 4‐20mA ; 4‐20mA+HART ; RS485 |
| Comprehensive accuracy | 0.075%FS ; 0.1 %FS ; 0.25%FS |
| Long term stability | ±0.1%FS/year |
| Nonlinearity | 0.1%FS |
| Repeatability | 0.05%FS |
| Storage temperature | ‐40～85℃ |
| Operating temperature | ‐20～85℃ |
| Compensation temperature | ‐10～80℃ |
| Body material | 304，316L |
| Isolation diaphragm material | SS316L ; Hastelloy C ; Tantalum (customizable) |
| Housing material | Flameproof Aluminum Alloy |
| Explosion-proof | CT4 ; CT6 |
| Protection grade | IP67 |
| Process connection | Standard 1/2NPT female；with 1/2NPT, G1/2 and M20*1.5, KF16 vacuum interface available |
Features
1.Adopts FST mono crystalline silicon MEMS chip to encapsulate
2.Accuracy +/-0.075% , Error less than +/-0.1%/10MPa
3.Advanced stability and static pressure performance
4.Excellent overload performance
5.Suitable for negative pressure measurement
6.Intelligent static pressure and temperature compensation
7.Internal integrated high sensitivity temperature transducer
8.All SS316L welding sealed construction with silicon filled
9.Fast response time
Application
Petrol oil, chemical industry, electrical power, paper making, iron and steel, coal gas and etc.
