Description
Technical Parameters
| Pressure range | -0.1～0～5MPa(Corrugated diaphragm) ; 0～2.5～70MPa(Flush diaphragm) |
| Overload | 150%FS |
| Comprehensive accuracy | 0.5%FS ; 1%FS |
| Long term stability | ±0.2%FS/year |
| Non-linearity | 0.2%FS |
| Repeatability | 0.2%FS |
| Singal output | 4‐20mA ; 0‐5V ; 0‐10V ; RS485 |
| Power supply | 24(12~36V)DC |
| Storage temperature | ‐40～85℃ |
| Operating temperature | ‐20～85℃ |
| Compensation temperature | ‐10～80℃ |
| On-site display | LCD digital display |
| Wetted material | SS304(customizable) |
| Housing material | Flameproof Aluminum housing ‐2088 |
| Protection grade | IP67 |
| Electrical Connection | Ex-proof metal gland ; M20*1.5 Ex-proof gland (external) ; M20*1.5 Ex-proof gland (internal) ; 1/2NPT Ex-proof gland (external) ; 1/2NPT Ex-proof gland (internal) ; G1/2Ex-proof gland (external) ; G1/2 Ex-proof gland (internal) ; M20*1.5 plastic gland |
| Process connection | G1/4 ; G1/2 ; 1/2NPT ; M20*1.5, etc. |
Features
1. Strong flush diaphragm, long service life
2. Use flameproof housing with LCD display
3. Compact structure, easy installation
4. Corrosion resistance, vibration resistance, particle impact resistance
Application
1. Polyurethane equipment
2. Papermaking industry
3. Paint manufacturing industry
4. Pharmaceutical industry
