Description
Technical Parameters
| Pressure range | 0~5MPa~35MPa |
| Overload | 150%FS |
| Comprehensive accuracy | ±1%FS(including linearity , repeatability & hysteresis) |
| Singal output | 4-20mA;0-10V;0-5V |
| Power supply | 24(12~36V)DC |
| Wetted material | Stainless Steel Coated with 15-5PH |
| Length of rod | 152;200;250;305;400mm |
| Standard cable | 5000mm |
| Optional cables | 1000;3000;8000;10000mm |
| Operating temperature | Max 400℃ |
| Protection grade | IP65; IP67 |
| Insulation resistance | 100MΩ / 250V |
| Zero point adjustment | Support |
| Full scale adjustment | Support |
| Internal calibration | 80% |
| Electrical Connection | 6PIN;1/2NPT Gland Lead |
| Process connection | Φ66;Φ82.6 USA Standard flange |
Features
1. Internal 80% calibration signal
2. Special flange installation, quick and easy installation
3. Good stability and repeatability
4. Zero point and full scale adjustable
Application
1.Chemical fiber drawing equipment
2.Plastic and rubber manufacturing equipment
3.Medicine, food processing, packaging equipment
4.Pressure measurement and control of other high-temperature fluid equipment
