Description
Technical Parameters
| Pressure range | 0~10MPa |
| Pointer accuracy | ±1.6%FS ; ±2.5%FS |
| Overload | 150%FS |
| Dial Filling Material | Silicone oil |
| Dial Diameter | 100mm |
| Max Diaphragm Temp. | 125℃ |
| Length of rod | 33 ; 82mm |
| Process Connection | 2″ Tri-clamp |
Features
1. High cost performance and long service life
2. Easy installation
3. Stainless steel package, good sealing
4. Good shock resistance, stability and repeatability
Application
1.Measurement of high viscosity, easy crystallization, easy solidification, and corrosive media
2.Alkali production, chemical fiber, printing and dyeing, petrochemical industry
3.Pharmaceuticals, food, cheese making, etc.
