Description
Technical Parameters
| Pressure range | 0~1MPa~10MPa |
| Overload | 150%FS |
| Display mode | Pointer |
| Pointer accuracy | ±1.6%FS ; ±2.5%FS |
| Dial diameter | 100mm |
| Operating temperature | Max 400℃ |
| Rigid stem length | 152 ; 200 ; 250 ; 305 ; 350 ; 400mm |
| Measuring diaphragm type | Corrugated diaphragm |
| Diaphragm diameter | 23.5mm |
| Process connection | Flange; DN50 ; DN125 ; DN205(customizable) |
Features
1. High cost performance, long service life
2. All stainless steel encapsulation
3. Flange installation, more stable structure
4. Corrugated diaphragm, small drift, stable performance
Application
1.Chemical fiber drawing equipment
2.Plastic and rubber manufacturing equipment
3.Medicine, food processing, packaging equipment
4.Pressure measurement and control of other high-temperature fluid equipment
