Description
Technical Parameters
| Pressure range | -0.1～0～6MPa |
| Overload | 150%FS |
| Comprehensive accuracy | 0.5%FS ; 1%FS |
| Long term stability | ±0.2%FS/year |
| Non-linearity | 0.2%FS |
| Repeatability | 0.2%FS |
| Singal output | 4‐20mA ; 0‐5V ; 0‐10V ; RS485 |
| Power supply | 24(12~36V)DC |
| Storage temperature | ‐40～85℃ |
| Operating temperature | ‐20～125℃ |
| Compensation temperature | ‐10～80℃ |
| On-site display | LCD digital display |
| Wetted material | SS316L(Customizable) |
| Housing material | Flameproof Aluminum housing ‐2088 |
| Protection grade | IP67 |
| Electrical Connection | Ex-proof metal gland ; M20*1.5 Ex-proof gland (external) ; M20*1.5 Ex-proof gland (internal) ; 1/2NPT Ex-proof gland (external) ; 1/2NPT Ex-proof gland (internal) ; G1/2Ex-proof gland (external) ; G1/2 Ex-proof gland (internal) ; M20*1.5 plastic gland |
| Process connection | Flange DN25 ; DN32 ; DN40 ; DN50 ; DN80 |
Features
1. Flameproof explosion-proof design, high safety
2. Adopt high-precision silicon sensor technology
3. Excellent static pressure performance (maximum static pressure can reach 32MPa)
4. Overload strong static pressure error is better than ≦ ±0.05%/10MPa
5. Optional HART communication protocol or RS485 digital signal
Application
1. Hydraulic and pneumatic control systems, liquid level measurement and control
2. Petrochemical, environmental protection (CEMS), pharmaceuticals
3. Power station operation inspection, locomotive braking system
4. Thermal power units, light industry, machinery, metallurgy
5. Industrial process detection and control
6. Building automation, constant pressure water supply, automatic control and detection systems
