Description
Technical Parameters
| Measurement range | 0~±200 N.m |
| Accruacy | 0.3% ; 0.1% |
| Power supply | 9~36V DC |
| Signal output | 5-15KHz 、4-20mA 、0-10V 、RS485、SPEED |
| Working speed | 0~10000 rpm |
| Response frequency | 100μS |
| Insulation resistance | >200MΩ |
| Zero drift | <0.5% |
| Operating temperature | -40~60℃ |
| Max load | 120%*FS |
| Repeatability | <0.1% |
| Linearity | <0.1% |
| Hysteresis | <0.1% |
Features
1.Can measure static torque and dynamic torque
2.When measuring forward and reverse torque, the signal uses digital technology and has strong anti-interference
3.No wear parts such as collector rings, and can run at high speed for a long time
4.High accuracy and good stability
5.Can measure forward and reverse torque, speed and power without adjusting the zero point
6.Small size, light weight, can be installed in any position and direction
Application
1. Motor
2. Centrifuge
3. Generator
4. Reducer
5. Diesel engine
