Description
Technical Parameters
| Measurement range | ‐100kPa～0-10kPa～5Mpa |
| Overload | 150%FS |
| Singal output | 4‐20mA ; 4‐20mA+HART ; RS485 |
| Power supply | 24(12~36V)DC |
| Comprehensive accuracy | 0.1%FS ; 0.25%FS ; 0.5%FS |
| Long term stability | ±0.1%FS/year |
| Non-linearity | 0.1%FS |
| Repeatability | 0.05%FS |
| Storage temperature | ‐40～85℃ |
| Operating temperature | ‐20～125℃ |
| Compensation temperature | ‐10～80℃ |
| Body material | SS316L |
| Process connection material | SS316L |
| Diaphragm material | SS316L ; Hastelloy C ; Tantalum (customizable) |
| Housing material | Flameproof aluminum housing |
| On-site display | LCD digital display |
| Protection grade | IP67 |
| Electrical Connection | Ex-proof metal gland ; M20*1.5 Ex-proof gland (external) ; M20*1.5 Ex-proof gland (internal) ; 1/2NPT Ex-proof gland (external) ; 1/2NPT Ex-proof gland (internal) ; G1/2Ex-proof gland (external) ; G1/2 Ex-proof gland (internal) ; M20*1.5 plastic gland |
| Process connection | Flange(DN50/DN80,customizable) ; Tri-clamp |
Features
1.Adopts high performance silicon
2.Strong anti-jamming performance
3.Error less than ±0.1%/10MPa
4.Internal integrated high sensitivity temperature transducer
5.Perfect thermal drift
6.Zero and full scale adjustment functions can be added.
7.Zero point and range can be adjusted on site by pressing buttons.
Application
1. Viscous media at high temperatures
2. Media that are easy to crystallize
3. Sedimentary media with solid particles or suspended matter
4. Highly corrosive or highly toxic media
5. It can eliminate the phenomenon of leakage of pressure pipes polluting the surrounding environment; it can avoid the tedious work of frequently replenishing isolation fluid due to the instability of the measurement signal when using isolation fluid
6. Continuous and accurate measurement of interface and density
7. The remote transmission device can avoid the mixing of media at different moments, so that the measurement results can truly reflect the actual situation of process changes
8. Occasions with high requirements for hygiene and cleanliness
