Description
Technical Parameters
| Product model | CZ-S500 | CZ-S150 |
| Measuring parameters | Refractive index (nD), temperature (T), Brix(%) | |
| Measurement range | nD; 1.33299-1.42009 / Brix; 0.0~50.0% | nD; 1.33299-1.35568 / Brix; 0.0~15.0% |
| Resolution | nD; 0.0001 / Brix; 0.1% / T; 0.1℃ | |
| Accuracy | nD; ±0.001 / Brix; ±1% / T; ±1℃ | |
| Temperature compensation | 10-60℃ | |
| Power supply | 12~24V DC | |
| Signal output | DC 4~20mA or RS485 | |
| Ambient temperature | 10-60℃ | |
| Protection grade | IP65 | |
| Operating pressure | Maximum tolerance 1Mpa | |
| High & low limit setting | Short circuit reset (4-20mA output) ; protocol reset (RS485 output) | |
| Prism material | Artificial sapphire | |
| Wetted material | Standard; SS316L | |
| Process medium | Cutting oil; emulsion; sugar content; juice | |
| Installation type | Tri-clamp | |
| Cleaning accessories | QX-S01、CQX-1A | |
| Pipeline adapter | Tri-clamp cross pipe fitting ; flange cross pipe fitting ; threaded cross pipe fitting | |
Features
1. Efficient and compact design
2. Continuous real-time concentration measurement output
3. Small and flexible probe installation
4. Definable intelligent output signal
5.No need for manual sampling to avoid biological contamination
Application
1. Real-time monitoring of soluble solids (Brix value) of products by various beverage manufacturers.
2. Continuous monitoring of soluble solids content (Brix value) in process flows such as evaporation, dissolution, mixing, dilution, and extraction.
3. Real-time detection of concentration of various industrial solutions, such as cutting oil, lubricating oil, cleaning fluid, emulsion, and release agent.
4. Concentration detection of various aqueous solutions (food, sauce, beer, wort, beverage, juice, pharmaceutical stock solution, chemical solution, slurry, etc.).
