Description
Technical Parameters
| Differential pressure measurement range | ‐100kPa～0-10kPa～5Mpa |
| Singal output | 4‐20mA ; RS485 |
| Power supply | 24(12~36V)DC |
| Comprehensive accuracy | 0.25%FS ; 0.5%FS |
| Long term stability | ±0.25%FS/year |
| Non-linearity | 0.2%FS |
| Repeatability | 0.15%FS |
| Storage temperature | ‐40～85℃ |
| Operating temperature | ‐10～85℃ |
| Compensation temperature | ‐10～80℃ |
| Body material | SS304 ; SS316L |
| Diaphragm material | SS316L ; Hastelloy C (customizable) |
| Housing material | SS304 |
| Protection grade | IP67 ; IP65 |
| Electrical Connection | Waterproof Metal Gland ; Hirschmann |
| Process connection | G1/4 ; G1/2 ; 1/2NPT ; 1/4NPT ; M12*1.5 |
Features
1.OEM provided
2.Various industrial standard signal output
3.Stainless steel structure is lightning-proof and corrosion-resistant
4.Good impact resistance and wide temperature range
5.Light weight, easy to install, maintenance-free
Application
1. Pipeline engineering
2. Measurement of various wind pressures and air pressures
3. Medical and health applications
4. Food and beverage processing industry
5. General industrial high-precision control field
