Description
Technical Parameters
| Pressure range | 0~5MPa~150MPa |
| Overload | 150%FS |
| Display mode | Pointer |
| Pointer accuracy | ±1.6%FS ; ±2.5%FS |
| Dial diameter | 100mm |
| Operating temperature | Max 400℃ |
| Rigid stem length | 152 ; 200 ; 250 ; 305 ; 350 ; 400mm |
| Capillary length | 460 ; 760 ; 1000 ; 1500 ; 2000mm |
| Process connection | 1/2″-20UNF ; M14*1.5 |
Features
1. Direct pressure display, no power supply required
2. Easy installation, flange edge can be added
3. Maximum temperature resistance 400℃
4. Good stability and repeatability
5. Can be customized according to customer requirements
Application
1.Chemical fiber drawing equipment
2.Plastic and rubber manufacturing equipment
3.Medicine, food processing, packaging equipment
4.Pressure measurement and control of other high-temperature fluid equipment
