Description
Technical Parameters
| Measurement range | 100~500mm H2O |
| Accuracy | 0.5%FS ; 1%FS |
| Overload | 150%FS |
| Long term stability | ±0.2%FS/year |
| Power supply | 12~36V DC |
| Signal output | 4~20mA ; 0-5V ; 0-10V ; RS485 |
| Electrical Connection | Waterproof Gland ; 5PIN |
| Storage temperature | -40~85℃ |
| Operating temperature | -20~125℃ |
| Compensation temperature | 0～65℃ |
| Body material | Stainless Steel |
| Protection grade | IP67 |
| Mounting interface | Thread |
Features
1.Can operate at high temperatures and pressure
2.Accurate and reliable measurement
3.Easy installation
4.Versatility across fluid types
5.Reliability and durability
Application
1. Truck mailbox liquid level monitoring
2. Industrial use to monitor liquid levels in tanks, containers and pipelines
3. Used in medical equipment to monitor liquid levels in infusion pumps, reservoirs or containers
4. Used in agriculture to monitor liquid levels in irrigation systems, fertilizer tanks and storage silos.
