Description
Technical Parameters
| Application types | Analog singnal transmitter (diffused silicon) | |
| Dimension | Diameter:Φ19mm | |
| Power supply and corresponding signal output |
Power supply | Signal output |
| 5V DC | 0-5V ; 0.5-4.5V | |
| (9-36) V DC | 0-5V ; 0.5-4.5V | |
| (12-36) V DC | 4-20mA ; 0-10V | |
| Pressure type | G: Gauge pressure | |
| A: Absolute pressure | ||
| Measurement range | -100kPa~0-10kPa~60MPa | |
| Zero output | ±2mV | |
| Full scale output | ≤250kPa; 50±5mV | ≤250kPa; 45±5mV |
| ≥500kPa; 60-140mV | ≥500kPa; 50-120mV | |
| Comprehensive accuracy | ±0.25%FS ; ±0.5%FS ; ±1%FS | |
| Operating temperature | -20℃～85℃ | |
| Storage temperature | -40℃～85℃ | |
| Temperature compensation | -10℃～70℃ | |
| Long term stability | ±0.3%/year | |
| Overload | 200%FS | |
| Insulation resistance | 100MΩ | |
| Housing / Isolation diaphragm material | SS316L ; Hastelloy C | |
| Filling liquid | Silicone oil | |
Features
1. Small structure, simple packaging available
2. Analog signal output
3. Multiple signal output options
4.Gauge pressure/absolute pressure is optional
Application
1. Precision control of industrial processes
2. Water supply and drainage systems
3. Hydraulic systems and switches
4. Liquid level measurement
5. Gas and liquid pressure measurement
