Description
Technical Parameters
| Pressure range | 0～3000～7000 psi |
| Comprehensive accuracy | 0.5%FS ; 1%FS |
| Singal output | 0~118mV， 0~59mV |
| Zero point output | 0~3mV |
| Overload | 200%FS |
| Response time | ≤5s |
| Operating temperature | ‐20～100℃ |
| Compensation temperature | 0～55℃ |
| Process connection | 11/16-24UNEF |
| Electrical Connection | 4P4C ; 6P4C ; 6P6C ; XH2.5-4P ; etc. |
| Protection grade | IP65 |
Features
1. The pressure chamber is constructed from a single piece of stainless steel, eliminating welds, O-rings, and potential leaks.
2. Simple structure, low cost, and high reliability.
Application
Specially used for spraying equipment
